Isdemir port is located within territories of iskenderun iron and steel works on iskenderun bay of the eastern mediterranean.It is 18 km away from the highway so called E 5.
The harbour entrance to be about 17 m. deep to within 70 m.of the north breakwater and to within about 30 m. of the south breakwater Max. draft is about 16,40 m. and the turning circle available at this draft is about 500 m. diameter. (port entry width : 325 meter)
Large vessels (over 100,000 d.w.t.) and tankers are not allowed to enter during hours of darknes, If vessel arrives with over 100,000 tones cargo or 16,40 m draft a fourth tug is berthing provided from Isdemir port.
OPERATOR COMPANY NAME :
Iskenderun Iron and Steel Works
OPERATOR ADRESS :
Demir Celik Fabrikalari, Payas, Iskenderun-Turkey |
| |
 |
| |
ISKENDERUN IRON AND STEEL WORKS FACTORY PORT |
PHONE |
+90.326.758 40 40 (switchboard) |
PORT DIRECTOR |
+90.326.758 30 80 or 758 33 80. |
PORT FAX |
+90.326.755 37 59 |
PIER MANAGER |
+90.326.758 53 80 |
MOBIL PHONE |
+90.536-638 36 58 ( PIER MANAGER ) |
EMAIL |
makarca@isdemir.com.tr ( PIER MANAGER) |
EMAIL |
tsaydam@isdemir.com.tr ( SECRETARY) |
ACCOUNT DPT |
+90.326.758 42 80 |
ISDEMIR PILOT |
+90.326.613 19 72 or +90.326.758 45 80 |
GATE( DOGUS ) |
+90.326.758 44 07 or +90.326.758 43 07 |
ISDEMIR CUSTOM OFFICE |
+90.326.758 30 02 or +90.326.758 53 02 |
CUSTOM OFFICE FAX |
+90.326.758 19 45 |
COAL WHARF |
+90.326.758 47 80 |
ISDEMIR TUGS OFFICE |
+90.326.758 46 80 |
ISDEMIR GUARD OFFICE |
+90.326.758 48 05 |
ISDEMIR DOLPHIN |
+90.326.758 33 55 |
Isdemir Port is situated within the site of Iskenderun Iron and Steel Works on the Iskenderun Bay Eastern Mediterranean. The port is protected by two breakwaters |
| |
LOCATION :-
36 43 30 North/ 36 11 04 East
36 43 40 North/ 36 11 14 East
LOCATED AT - ANCHORAGE :
36 44 30 North / 36 08 30 East
INFORMATION ON BEST LOCATION OF ANCHORAGE WILL BE GIVEN BY ISDEMIR PILOT VHF CHANNEL 12.
ADMIRALTY CHART NO :
2185 B.A.
PILOT :
isdemir Pilot vhf chanel 16 / 12
Pls call isdemir pilot prior to 20 miles for berthing or anchorage. manouvering channel 12 |
| |
ISDEMIR PORT BERTH ( COAL AND ORE ) |
UNLOADING DOCK NO : |
AI ( COAL AND ORE ) |
Dock Lenght |
500 m |
Vessel size |
150.000 DWT |
Dock Depth |
18,50m |
Max.vsl draf |
16,40 m |
Unloading capacity |
abt max 2500 tons/ hour |
Crane |
2 ( 2 x 1250 ton / hrs) |
Air draft |
25 meter |
|
|
UNLOADING DOCK NO : |
AB ( COAL AND ORE ) |
Dock Lenght |
240 m |
Vessel size |
50.000 DWT |
Dock Depth |
12 m |
Max.vsl draft |
11,5 m |
Unloading capacity |
BULK, abt max 1600 tons/ hour |
Crane |
4 ( 4 x 400 ton /hrs) |
Unloading capacity |
G.CARGO, 600 tons/ hour |
Crane |
4 ( 4 x 150 ton /hrs) |
Air draft |
25 meter |
COAL DISCHARGE A DAY |
MAX..: 20.000 MT ..... MIN..: 16.000 MT |
|
| |
ISDEMIR PORT BERTH ( GENERAL CARGO ) |
UNLOADING DOCK NO : |
CD (GENERAL CARGO ) |
Dock Lenght |
220 m |
Vessel size |
8.500 DWT |
Dock Depth |
8 m |
Max.vsl draft |
7,6 m |
Unloading capacity |
G.CARGO, abt max 300 tons/ hour |
Crane |
2 ( 2 x 150 ton /hrs |
UNLOADING DOCK NO |
DE (GENERAL CARGO ) |
Dock Lenght |
200 m |
Vessel size |
35000 DWT |
Dock Depth |
10 m |
Max.vsl draft |
9,4 m |
Unloading capacity |
G.CARGO, abt max 140 tons |
Crane |
1 ( 1 x 140 ton lifting) |
UNLOADING DOCK NO |
EF (GENERAL CARGO ) |
Dock Lenght |
185 m |
Vessel size |
37.000 DWT |
Dock Depth |
10 m |
Max.vsl draft |
9,4 m |
Unloading capacity |
BULK, abt max 900 mt/ph |
Unloading capacity |
G.Cargo, 450 mt/ph |
|
| |
THE DOLPHIN ( OIL) WHARF --- ( FOR TANKER BERTH )
DOLPHIN DOCK NO :
Dock Lenght............ : 106 m
Vessel size............... : 60.000 DWT
Dock Depth.............. : 14 m
Max.vsl aft draft..... : aft 13 m
Unloading capacity : Fuel oil, abt 500 mt/ph
Hose........................... : 1 x 8 " 150 asa ( stern line )
Breakwater ..............: No , Open sea
Berthing ................... : vessel will first drop 2 anchor and than be to be connected to the dolphin at aft ( stb side - port side ) 2 or 3 mooring lines at stb and port side.
Distance fm dolphin manifod to ship manifold : abt 4 meters ( contact to agent for more info ) 3 x 6 = 18 meter flexible hose will be connected |
| |
ISDEMIR PORT BERTH ( M ) |
LENGHT ( M ) |
DRAFT ( M ) |
wharf no AI.. ( coal,ore berth ) |
500 |
16,40 |
wharf no AB .( coal, ore berth ) |
240 |
11,50 |
wharf no CD .( all cargo ) |
220 |
07,60 |
wharf no DE .( all cargo ) |
200 |
09,40 |
wharf no EF .( all cargo ) |
185 |
09,40 |
wharf no FG. ( all cargo ) |
090 |
05,50 |
Dolphin OIL . ( tanker ) |
106 |
13,00 |
|
| |
WATER DENSTIY:
1025
Storage Area Open......: 120,000 m2,
Warehouse............... : 10,500 m2,
Fuel oil tanks .............: 55.000 mt( 9 Tank x 5000 mt and 1 tank 10.000 mt )
BERTHING/UNBERTHING:-
This is cargo over 100.000 mt
Large vessels (over 100,000 d.w.t.) and tankers are not allowed to enter during hours of darknes, If vessel arrives with over 100,000 tones cargo and berthing will be
4 tugboat and unberthing 3 tugboat.Daylight berthing fm 0600 to sunset. |
| |
NIGHT BERTHING/UNBERTHING....... : ( YES) W.P
BREAKWATER ..............: ( Yes )
FRESH WATER AVAILABLE : ( Yes ) each ton 5 usd.
STRAIGHT TIME WORKING HOURS : 24 hrs
GARBAGE DISPOSAL ..... .: service available
ADANA AIRPORT TO PORT ...: Distance abt.. 120 km. from isdemir port.
-ISDEMIR GATE :- ( FOR ENTRANCE PERMIT )
SHIP AGENT MUST SEND BY EMAIL OR FAX LETTER TO ISDEMIR PORT AUTHORITY.
PLEASE, CALL TO ISDEMIR PORT AUTHORITY MORE INFORMATION.
ALL PERSONNEL WITHIN THE PORT (INCL AGENT OFFICER ,SURVEYORS AND VISITORS) MUST BE PROVIDED WITH VISITOR PASS OR A CLEAR IDENTIFIABLE IDENTIFICATION CARD.
PHONE.... : + 90.326.758 53 80 - MR. MUSTAFA AKARCA
FAX ........ : +90.326.755 37 59
EMAIL...... : makarca@isdemir.com.tr (PORT PIER MANAGER)
EMAIL...... : tsaydam@isdemir.com.tr (PORT PIER MANAGER SECRETARY )
- PORT STATE CONTROL:-
PORT STATE CONTROL COMMENCED IN ISKENDERUN.
ISDEMIR PORT:-
PRESENT SECURITY LEVEL IS ONE (1)
ISPS OFFICER : MUSTAFA AKARCA
PHONE.... : +90.326.758 40 40 (switchboard)
PHONE.... : +90.326.758 53 80
FAX ....... : +90.326.755 37 59
MOBIL..... : +90.536-638 36 58
EMAIL : makarca@isdemir.com.tr |
| |
